HP ProDisplay P201 User Manual

Altitude - Operating +0 to 5,000 m (16,404 ft)
Altitude - Non-operating 0 to 12,192 m (0 to 40,000 ft)
White LED Backlights Yes
CCFL Panel No
Arsenic-Free Display
Glass
4
Yes
Low Halogen5 Yes
Mercury Free Display
Backlighting
Yes
Environmental Data Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 06
EPEAT® Gold where HP registers commercial desktop products. See
http://www.epeat.net for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
ENERGY STAR® test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 15.7 W 15.8 W NA W
Sleep 0.3 W 0.3 W NA W
Off 0.25 W 0.25 W NA W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 53 BTU/hr 54 BTU/hr NA BTU/hr
Sleep 1.0 BTU/hr 1.0 BTU/hr NA BTU/hr
Off 0.8 BTU/hr 0.8 BTU/hr NA BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 13 % post-consumer recycled plastic (by wt.)
This product is 97.1 % recycle-able when properly disposed of at end of
life.
QuickSpecs
HP ProDisplay P201 20-inch LED Backlit Monitor
Technical Specifications
DA - 14486 Worldwide — Version 6 — July 12, 2013 Page 5

HP ProDisplay P201 Specifications

General

3D	No
HD type	-
Pixel pitch	0.2768 x 0.2768 mm
Display surface	Matt
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1600 x 900
On/off switch	Yes
Ethernet LAN (RJ-45) ports	0
LED indicators	Power
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Certification	TCO
Product color	Black
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DVI, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	151.1 mm
Height (with stand)	359.2 mm
Depth (without stand)	47.5 mm
Width (without stand)	482 mm
Height (without stand)	294.1 mm
Weight (without stand)	3500 g
