Server component identification 48
Item LED Description Status
4 DIMM 3B failure Amber = DIMM has failed.
Off = DIMM is operating normally
5 DIMM 2A failure Amber = DIMM has failed.
Off = DIMM is operating normally.
6 DIMM 1A failure Amber = DIMM has failed.
Off = DIMM is operating normally
7 Overtemperature
Amber = System has reached cautionary or
critical temperature level.
Off = Temperature is OK.
8 Processor 1 failure .Amber = Processor has failed.
Off = Processor is operating normally.
9 PPM 1 failure Amber = PPM has failed.
Off = PPM is operating normally.
10 PPM 2 failure Amber = PPM has failed.
Off = PPM is operating normally
11 Processor 2 failure Amber = Processor has failed.
Off = Processor is operating normally.
12
Power supply signal
connector interlock
failure
Amber = Power supply signal cable is not
connected.
Off = Power supply signal cable is connected.
13
Standby power
good
Green = Auxiliary power is applied.
Off = Auxiliary power is not applied.
14
Power supply fan
module failure
Amber = One fan in this module has failed.
Red = Multiple fans in this module have
failed.
Off = All fans in this module are operating
normally.
15 System diagnostic
Refer to the HP Remote Lights-Out Edition II
User Guide on the Documentation CD.
16
Online spare
memory
Amber = Failover has occurred. Online spare
memory is in use.
Green = Online spare memory is enabled,
but not in use.
Off = Online spare memory is disabled.
17 Riser interlock Amber = PCI riser assembly is not seated.
Off = PCI riser assembly is seated.
System LEDs and internal health LED combinations
When the internal health LED on the front panel illuminates either amber or red, the server is experiencing
a health event. Combinations of illuminated system LEDs and the internal health LED indicate system
status.
The front panel health LEDs indicate only the current hardware status. In some situations, HP SIM may
report server status differently than the health LEDs because the software tracks more system attributes.
