Illustrated parts catalog 7
System components
Item Description
Spare Part
Number
Customer Self
Repair
System Components
1 Power supply fan assembly 361399-001 Yes
2 Processor fan assembly 361390-001 Yes
3 Hot-plug power supply, 460 W 361392-001 Yes
4 PCI riser bracket, with PCI riser boards 361387-001 Yes
5 Processor/heatsink assembly
a) Intel® 3.40-GHz Xeon™ 2-MB L2 cache * 381800-001 Yes
b) Intel® 3.60-GHz Xeon™ 2-MB L2 cache * 381799-001 Yes
c) Intel® 3.80-GHz Xeon™ 2-MB L2 cache 800 MHz FSB * 381798-001 Yes
d) Intel® 3.00-GHz Xeon™ 2-MB L2 cache LV * 397864-001 Yes
e) Intel® 2.80-GHz Xeon™ 2-MB L2 cache * 403625-001 Yes
6 a) 3.6-V 500 mAh NiMh battery * 307132-001 Yes
b) Universal battery housing with cable 349989-001 Yes
7 Smart Array 6i 128-MB DDR 40-bit memory module 351518-001 Yes
Boards
8 System board, with processor cages and system battery
