HP ProLiant DL370 Generation 6 User Manual

Expansion Slots NOTE: Nine (9) available PCI-Express Gen2 expansion slots to provide you with the latest I/O performance;
PCI-X (optional).
Expansion Slots
#
Technology Bus Width Connector
Width
Form Factor Notes
1 PCIe x4 x8 Half length, full
height
2 PCIe2 x4 x8 Full Length/Full
Height
3 PCIe2 x16 x16 Full Length/Full
Height
4 PCIe2 x4 x8 Full Length/Full
Height
5 PCIe2 x4 x8 Full Length/Full
Height
6 PCIe2 x8 x16 Full Length/Full
Height
7 PCIe2 x4 x8 Full Length/Full
Height
8 PCIe2 x16 x16 Full Length/Full
Height
9 PCIe2 x4 x8 Full Length/Full
Height
10 PCIe2 X8 X8 Half length, full
height
Utilized by NIC
controller "Use
the correct
model number
for the NIC"
11 PCI-X See note See note Full Length/Full
Height
(optional) *Up to
64bits/133Mhz
speed when only
one device
install in slot 11
and 12
*up to
64bits/100Mhz
speed when both
slot 11 and 12
are utilized.
12 PCI-X See note See note Full Length/Full
Height
(optional)
*Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
*Only PCI-X support is available in slot 4, supporting PCI-X cards. PCI legacy cards are not supported.
QuickSpecs
HP ProLiant DL370 Generation 6 (G6)
HP ProLiant ML370 Generation 6 (G6)
Standard Features
DA - 13242 Worldwide — Version 58 — February 27, 2013 Page 5

HP ProLiant DL370 Generation 6 Specifications

General

Memory	Up to 192 GB DDR3 Registered or Unbuffered DIMMs
Chipset	Intel 5520 chipset
Processor	Intel Xeon 5500 and 5600 series
Storage	Up to 16 SFF (2.5-inch) or 8 LFF (3.5-inch) drives
Network	Embedded NC382i Dual Port Gigabit Ethernet or optional adapters
Power Supply	1200W
Expansion Slots	Up to 6 PCI-e Gen2 slots
Management	Integrated Lights-Out 2 (iLO 2) standard
Form Factor	5U rack
