Illustrated parts catalog 23
Item Description Assembly part
number
Spare part
number
Customer self
repair (on
page 6)
16 PPM 399854-001 407748-001 Mandatory
1
17 System boards — — —
a) System board with processor cage and
battery, supporting Intel® Xeon® 50xx and
51xx processors*
012516-001 407749-001 Optional
2
b) System board with processor cage and
battery, supporting Intel® Xeon® 53xx and
54xx processors*
013096-001 436526-001 Optional
2
18 Power supply backplane 399428-001 407750-001 Mandatory
1
19 Hard drive backplane, 8-bay 012531-001 407751-001 Mandatory
1
20 Fan board — — —
a) Fan board, 12-fan model 012525-001 408791-001 Optional
2
b) Fan board, 6-fan model* 012525-001 442955-001 Optional
2
21 Systems Insight Display with cover 397258-001 408792-001 Mandatory
1
Media drives
22 Diskette drive, slimline (optional) 263394-002 399396-001 Mandatory
1
23 CD-ROM drive, removable slimline
(optional)*
222837-003 399401-001 Mandatory
1
24 DVD-ROM drive, removable slimline, 8X/24X
(optional)*
395910-001 397928-001 Mandatory
1
25 CD-RW/DVD-ROM drive, slimline, 24X
(optional)*
383696-002 399959-001 Mandatory
1
26 DVD+R/RW drive, slimline, 8X* 395911-001 399402-001 Mandatory
1
Cables
27 Miscellaneous cable kit* — 408795-001 Mandatory
1
a) Power cable, 10-pin 394038-001 — —
b) Systems Insight Display cable 219049-003 — —
28 SAS cable* 361316-010 408796-001 Mandatory
1
29 Data cable kit* — 408797-001 Mandatory
1
a) Fan board cable 372616-002 — —
b) Media drive multibay cable 356452-003 — —
Rack mounting hardware
30 Rack mounting hardware kit* 360322-003 359254-001 Mandatory
1
Miscellaneous
31 Hardware kit* — 407752-001 Mandatory
1
a) Retainer spring 397450-001 — —
b) Screws, 6-32 × 0.200 TT, Hi/TP (4)
(media drive ejector assembly, media drive
cable, external option blank)
192308-009 — —
