Illustrated parts catalog 24
Item Description Assembly part
number
Spare part
number
Customer self
repair (on
page 6)
c) Hard drive cage screws, 6-32 × 0.125, T-
15, (2)
242966-006 — —
d) Front bezel screws, T-15, flat-head (2) 228213-003 — —
e) Expansion slot cover, short 394041-001 — —
f) Thumbscrew, molded cap 179333-003 — —
g) Thumbscrew assembly, right-attach 405895-002 — —
h) Thumbscrew assembly, left-attach 405895-001 — —
32 Plastics kit* — 407753-001 Mandatory
1
a) PPM retainer (2) 390534-001 — —
b) PCI retainer, low-profile (2) 397873-001 — —
c) Hard drive backplane retainer 397449-001 — —
d) T-10/T-15 Torx screwdriver holder 373134-001 — —
e) PCI card guide retainer 379046-002 — —
f) Power cord retainer clip 352993-001 — —
33 Miscellaneous rubber grommet isolation kit — 430370-001 Mandatory
1
34 AC power cord* 142263-001 142258-001 Mandatory
1
35 Media drive ejector assembly* 394022-001 409007-001 Mandatory
1
36 Battery, 3.3-V, lithium* 166899-001 153099-001 Mandatory
1
37 Return kit, pack box, and cushions* — 289545-001 Mandatory
1
38 T-10/T-15 Torx screwdriver* 377511-001 413965-001 Mandatory
1
Memory
39 512-MB, registered PC2-5300 FBDIMM* 398705-051 416470-001 Mandatory
1
40 1-GB, registered PC2-5300 FBDIMM* 398706-051 416471-001 Mandatory
1
41 2-GB, registered PC2-5300 FBDIMM* 398707-051 416472-001 Mandatory
1
42 4-GB, registered, PC2-5300 FBDIMM* 398708-061 416473-001 Mandatory
1
Options
43 Hot-plug SAS hard drive* — — —
a) 36-GB, 10,000-rpm, 6.35-cm (2.5-in) 375859-B21 376596-001 Mandatory
1
b) 36-GB, 15,000-rpm, 6.35-cm (2.5-in) 431933-B21 432322-001 Mandatory
1
c) 72-GB, 10,000-rpm, 6.35-cm (2.5-in) 375861-B21 376597-001 Mandatory
1
d) 72-GB, 15,000-rpm, 6.35-cm (2.5-in) 431935-B21 432321-001 Mandatory
1
e) 146-GB, 10,000-rpm, 6.35-cm (2.5-in) 431958-B21 432320-001 Mandatory
1
44 Hot-plug SFF SATA hard drive* — — —
a) 60-GB, 5,400-rpm, 1-year warranty 379306-B21 382264-001 Mandatory
1
b) 120-GB, 5,400-rpm, 1-year warranty 431786-B21 431908-001 Mandatory
1
45 HP Smart Array E200 Controller* 012891-001 412799-001 Optional
2
