Illustrated parts catalog 20
Item Description
Spare part
number
Customer self
repair (on
page 5)
e) 2.4-GHz Intel® Xeon® 3060, 1066-MHz FSB, 4-
MB L2 cache *
432943-001 Optional
2
f) 1.87-GHz Intel® Xeon® 3040, 1066-MHz FSB,
2x1-MB L2 cache *
436522-001 Optional
2
Memory
12 DIMM — —
a) 2-GB, PC2-5300 unbuffered, advanced ECC
DIMM *
433935-001 Mandatory
1
b) 1-GB, PC2-5300 unbuffered, advanced ECC
DIMM *
432930-001 Mandatory
1
c) 512-MB, PC2-5300 unbuffered, advanced ECC
DIMM *
433555-001 Mandatory
1
Boards
13 System board with tray 432473-001 Optional
2
14 Power button/LED board, with front panel assembly 398403-001 Mandatory
1
15 SAS/SATA backplane board * 404179-001 Mandatory
1
Mass storage devices
16 Hard drive — —
a) 36-GB, SAS LFF, 15,000-rpm 376593-001 Mandatory
1
b) 72-GB, SAS LFF, 15,000-rpm * 376594-001 Mandatory
1
c) 146-GB, SAS LFF, 15,000-rpm * 375877-001 Mandatory
1
d) 80-GB, SATA LFF, 7,200-rpm * 397551-001 Mandatory
1
e) 160-GB, SATA LFF, 7,200-rpm * 397552-001 Mandatory
1
f) 250-GB, SATA LFF, 7,200-rpm * 397553-001 Mandatory
1
g) 500-GB, SATA LFF, 7,200-rpm * 395501-001 Mandatory
1
h) 750-GB, SATA LFF, 7,200-rpm * 432401-001 Mandatory
1
17 IDE CD-ROM drive (48X) 397931-001 Mandatory
1
Power
18 Redundant power supply backplane assembly * 432478-001 Mandatory
1
19 Redundant power supply, 430-W 432479-001 Mandatory
1
20 Non-redundant power supply, 410-W * 432477-001 Mandatory
1
21 Battery, 3-V, 200-mAh internal lithium * 234556-001 Mandatory
1
Cable assembly
22 IDE CD-ROM drive cable assembly * 403039-001 Mandatory
1
23 Hot-plug SATA/SAS cable assembly * 384754-001 Mandatory
1
24 Power button/LED board cable assembly * 403042-001 Mandatory
1
25 Front USB connector cable assembly * 403043-001 Mandatory
1
Miscellaneous
26 Bezel key * 405168-001 Mandatory
1
