Removal and replacement procedures 43
CAUTION: Heatsink retaining screws should be tightened in diagonally opposite pairs (in an "X" pattern).
8. Install the system fan air baffle.
9. Install the access panel.
10. Install the bezel.
11. Power up the server.
Expansion boards
To remove the component:
1. Power down the server (on page 25).
2. Remove the server from the rack, if necessary ("Remove the server from the rack" on page 25).
3. Remove the bezel ("Unlock the tower bezel" on page 26).
4. Remove the access panel ("Access panel" on page 26).
5. Remove the expansion board.
