Removal and replacement procedures 50
7.
Apply all the grease to the top of the processor in one of the following patterns to ensure even
distribution:
8. Install the heatsink.
CAUTION: Heatsink retaining screws should be tightened in diagonally opposite pairs (in an "X" pattern).
9. Install all components removed from the failed system board.
IMPORTANT: Install all components with the same configuration that was used on the failed system board.
10. Power up the server.
After you replace the system board, you must re-enter the server serial number and the product ID.
1. During the server startup sequence, press the F9 key to access RBSU.
2. Select the Advanced Options menu.
3. Select Serial Number. The following warning is displayed:
Warning: The serial number should ONLY be modified by qualified service
personnel. This value should always match the serial number located on
the chassis.
