Component identification 69
Item Description
17 System maintenance switch
18 PCI fan connector
19 System battery
20 SATA connector 4 (hard drive)
21 SATA connector 6 (optical drive)
22 Internal USB connector
23 PCI-X extender board connector
24 SATA connector 5 (optical drive)
25 USB tape drive connector
26 Diskette drive connector
27 SATA connector 3 (hard drive)
28 SATA connector 1 (hard drive)
29 Pa rallel connector
30 Seria l connector
31 PCI Express expansion slot 3
32 Reserved
33 PCI Express expansion slot 5*
34 PCI Express expansion slot 6*
35 Rear fan connector
36 PCI Express expansion slot 7*
37 Reserved
* x8 PCI Express cards are supported, but will run at x1 speeds.
System maintenance switch
Position Default Function
S1 Off Off = iLO 2 security is enabled
On = iLO 2 security is disabled
S2 Off Off = System configuration can
be changed
On = System configuration is
locked
S3 Off Reserved
S4 Off Reserved
S5 Off Off = No function
On = Clears power-on
password and administrator
password
S6 Off Off = Normal
On = ROM treats system
configuration as invalid
