Server Component Identification 17
System LED and
Color
Internal Health
LED Color
Status
Processor failure,
socket X (Amber)
Red One or more of the following conditions may exist:
•
•
•
•
•
Processor in socket X has failed.
Processor in socket X failed over to the second
processor.
Processor X is not installed in the socket.
Processor X is not supported.
Processor heatsink is not attached properly.
Amber Processor in socket X is in a pre-failure condition.
Processor failure,
both sockets (Amber)
Red Processor types are mismatched.
PPM failure (Amber) Red •
•
PPM has failed.
PPM is not installed, but the corresponding processor
is installed.
DIMM failure, slot X
(Amber)
Red •
•
DIMM in slot X has failed.
DIMM in slot X is an unsupported type, and no valid
memory exists in another bank.
Amber •
•
•
DIMM in slot X has reached single-bit correctable
error threshold.
DIMM in slot X is in a pre-failure condition.
DIMM in slot X is an unsupported type, but valid
memory exists in another bank.
Overtemperature
(Amber)
Red •
•
The Health Driver has detected a cautionary
temperature level.
The server has detected a hardware critical
temperature level.
Fan (Amber) Red The minimum fan requirements are not being met. Fan
has failed.
Amber A fan has failed but still meets the minimum fan
requirements (with redundant fan option only).
