34 Reference and Troubleshooting Guide
Item Description
6 64-bit 100 MHz PCI-X slot, bus 9, slot 3
7 64-bit 100 MHz PCI-X slot, bus 9, slot 4
8 64-bit 133 MHz PCI-X slot, bus 6, slot 5
9 64-bit 66 MHz PCI-X slot, bus, 2, slot 6
10 RJ-45 Ethernet connector
11 USB 2.0 connectors (2)
12 Video connector
13 Parallel connector
14 Serial connector
15 Keyboard connector
16 Mouse connector
2. Connect the power cord to the back of the server.
3. Connect the power cord to the AC power source.
WARNING: To reduce the risk of electric shock or damage
to the equipment:
Do not disable the power cord grounding plug. The grounding
plug is an important safety feature.
•
•
•
Plug the power cord into a grounded (earthed) electrical outlet
that is easily accessible at all times.
Unplug the power cord from the power supply to disconnect
power to the equipment.
Do not route the power cord where it can be walked on or pinched
by items placed against it. Pay particular attention to the plug,
electrical outlet, and the point where the cord extends from the
server.
Installing the Server into the Rack
Follow the steps in this section to install the server into either a round-hole or
square-hole rack.
