58 Reference and Troubleshooting Guide
Installing a Half-Height or Full-Height Media Device Option
The server includes four removable media bays. The lower two bays are
occupied with a 3.5-inch diskette drive and an IDE CD-ROM drive. The upper
two removable media bays are vacant. You can install up to two half-height or
one full-height removable media devices in the removable media cage. To install
a half-height or full-height media device:
1. Power down the server ("Powering Down the Server" on page 21
).
2. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 22
).
3. Remove the front bezel door, if necessary ("Removing Front Tower Bezel"
on page 23
).
4. Remove the access panel ("Removing Access Panel" on page 23
).
5. Remove the media device blanks.
6. Configure the device by setting the SCSI ID. The SCSI ID on each device in
the media bays must be manually set to a unique value. Refer to the
documentation provided with the device for instructions on setting the SCSI
ID.
7. Remove all terminating jumpers from third-party SCSI devices.
8. Install the guide screws ("Identifying Guide Screws" on page 55
), if
applicable.
