Hardware Options Installation 57
8. Replace the front bezel ("Removing Front Tower Bezel" on page 23), if
applicable.
9. Replace the access panel ("Removing Access Panel" on page 23
).
Removing Shipping Brackets
Shipping brackets prevent the drive cage from moving while the server is being
shipped.
NOTE: The shipping brackets do not need to be removed from the
server when the server is in normal operation.
Before installing an option into the removable media bay area, remove the
shipping brackets. To remove shipping brackets:
1. Loosen the thumbscrew securing the shipping bracket to the server.
2. Remove the shipping bracket.
3. Before shipping the server with an option installed in the removable media
bay, reverse steps 1 and 2 to install the shipping brackets.
