56 Reference and Troubleshooting Guide
Accessing the Removable Media Cage
The server supports installation of optional internal storage devices.
IMPORTANT: HP and Compaq branded SCSI non-hot-plug cables are
terminated. Remove all terminating jumpers from third-party SCSI
devices before installing them in the server.
1. Power down the server ("Powering Down the Server" on page 21).
2. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 22
).
3. Remove the front bezel door, if necessary ("Removing Front Tower Bezel"
on page 23
).
4. Remove the access panel ("Removing Access Panel" on page 23
).
CAUTION: Always populate each media bay with either a
device or a blank. Proper airflow can only be maintained when the bays
are populated. Unpopulated drive bays can lead to improper cooling and
thermal damage.
5. Remove the shipping bracket ("Removing Shipping Brackets" on page 57).
6. Push up on the drivelock to release the blanks and gently pull it away from
the chassis.
7. Install other hardware options as needed.
