Page #16 background imageLoading...
Page #16 background image
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered,
HP recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable
product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered
with the server.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
[Chassis]
HP ProLiant ML350 Gen9 Hot Plug
8SFF Configure-to-order Rack
Server
HP ProLiant ML350 Gen9 Hot Plug
8SFF Configure-to-order Tower
Server
HP ProLiant ML350 Gen9 Hot Plug
8LFF Configure-to-order Tower
Server
SKU Number
754534-B21 754536-B21 754537-B21
Processor
2 (optional) x HP Smart Socket Guides
DIMMSlots
24 DIMM slots for RDIMM, LRDIMM DDR4 Memory
Storage Controller
HP Dynamic Smart Array B140i
PCIe
9 Standard (8 FH/FL, 1 FH/HL)
Drive Cage
8SFF Hot Plug
8LFF Hot Plug
Network Controller
HP Embedded 1Gb Ethernet 4-port 331i Adapter
Fans
3 hot plug fans, non redundant
Management
iLO Management (standard), Intelligent Provisioning (standard), iLO Advanced (optional), Insight Control
(optional)
USB
2 front, 2 internal, 4 rear
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
HP Processors
Select one or two processors from Core options-Processor section below,
If one processor is desired, select one xxxxxx-L21
If two processors are desired, select one xxxxxx-L21 and one xxxxxx-B21.
Up to 2 processors supported. Mixing different processor models is not supported.
DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on
the quantity and type of DIMMs installed.
For the Intel® C600 Chipset E5-2600 Series, the letter preceding the model number indicates the Product
Line (E3, E5, E7); 2600x v#, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 = Processor
SKU, x = L for low power SKUs and v# (not yet designated) = version number.
HP Memory
Select one or more memory from Core options-Memory section below,
LRDIMM, RDIMM are all distinct memory technologies and cannot be mixed within a server. The
majority of ProLiant Gen9 servers support LRDIMM and RDIMM.
HP memory from previous generation servers are not qualified or warranted with this HP ProLiant
Server. HP SmartMemory is required to realize the memory performance improvements and
enhanced functionality listed in this document for Gen9.
If only one processor is installed, only half of the total DIMM slots are available. When populating
with two processors all DIMM slots are available.
Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient
Features, see:
www.hp.com/go/proliant-energy-efficient
.
Depending on the memory configuration and processor model, the memory speed may run at
2133MHz, 1866MHz, 1600MHz or 1333MHz. Please see Memory Population Table or the Online
Memory Configuration Tool at:
www.hp.com/go/ddr4memory-configurator
QuickSpecs
HP ProLiant ML350 Generation9 (Gen9)
Configuration Information - Factory Integrated Models
DA - 15035 Worldwide QuickSpecs — Version 2 — 9.23.2014
Page 16
