HP ProLiant ML350e Gen 8 v2 - Tools Required for Disassembly; Torx Driver; Philips screw driver; Flat Head screw driver

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Torx Driver
T-15
Philps screw driver
#2
Flat Head screw driver
Medium
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Remove the top cover and locate the battery on the system board.
2. Capacitors in 460W ATX power supply=> 2.5 cm () - Remove the power supply from the system with a T-15 torx
driver. With a #2 Philips screw driver remove the screws securing the top cover then locate the capacitors and pry from
the PCB with a flat head screw driver or Long Nose Plier () and dispose of properly.
3. Capacitors in 460W and 750W redundant power supply=> 2.5 cm () - Remove the power supply from the system with
a T-15 torx driver. With a #2 Philips screw driver remove the screws securing the top cover then locate the capacitors
and pry from the PCB with a flat head screw driver or Long Nose Plier and dispose of properly.
4.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1 –RTC location
Attachment 2-4- 2.5cm Capacitor location
