Removal and replacement procedures 31
1.
Open the front bezel (tower servers only).
IMPORTANT: You must unlock the front bezel before removing the access panel.
2. Lift up the front bezel, and remove it from the chassis.
To replace the component, reverse the removal procedure.
Access panel
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
CAUTION: Do not operate the server for long periods with the access panel open or removed.
Operating the server in this manner results in improper airflow and improper cooling that can
lead to thermal damage.
To remove the component:
1. Power down the server (on page 29).
2. Extend or remove the server from the rack ("Extend the server from the rack" on page 29, "Remove the
server from the rack" on page 30).
3. Open the front bezel ("Front bezel" on page 30).
4. Using a T-10/T-15 Torx screwdriver, unlock the access panel locking latch.
5. Lift up on the hood latch handle and remove the access panel.
To replace the component, reverse the removal procedure.
Rack bezel
To remove the component:
