Removal and replacement procedures 41
5.
Remove the expansion slot cover.
Retain the slot cover for future use.
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all PCI slots have either an expansion slot cover or an expansion board installed.
To replace the component, reverse the removal procedure.
Expansion board
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the expansion boards.
To remove the component:
1. Power down the server (on page 29).
2. Extend the server from the rack, if applicable ("Extend the server from the rack" on page 29).
3. Remove the access panel ("Access panel" on page 31).
4. Disconnect any cables attached to the expansion board.
