Server component identification 89
Item Description Status
12
Internal system health LED Green = Normal (system on)
Amber = System health is degraded
Red = System health is critical
Off = Normal (system off)
13
External system health LED
(power supply)
Green = Normal (system on)
Amber = Redundant power supply failure
Red = Power supply failure. No operational power supplies.
Off = Normal (system off)
14
Overtemperature LED Red = Overheating, critical
Off = Normal
15
System power LED Green = System has AC power and is powered on
Amber = System has AC power and is in standby mode
Off = System has no AC power
* If all FBDIMM LEDs for a memory board are flashing, the memory board is unseated.
