Other Interfaces
IrDA (SIR)
USB 1.1 Client
– supported via HP standard 22-pin sync connector interface
Serial RS232
– supported via HP standard 22-pin cable interface (cable must be purchased separately)
NOTE:
Some HP authorized options may not be supported. See
http://www.hp.com/go/ipaqaccessories
.
SD Slot
Support 1-bit/4-bit SDIO, SD/Multimedia Card type memory standard, and mini SD memory cards with SD
adapters
Power Supply
Battery
Removable/rechargeable 1100 mAh Lithium-lon (user changeable).
Optional extended 1800 mAh Lithium-lon battery available for purchase
(
http://www.hp.com/go/ipaqaccessories
).
AC Power
AC Input: 100~240 Vac, 50/60 Hz, AC Input current: 0.3 Aac max
Output Voltage: 5Vdc (typical), Output Current: 2A (typical)
NOTE:
Battery run time varies based on the usage pattern of an individual user and the configuration of
the handheld. Use of internal wireless capabilities and backlight will significantly decrease battery run
time.
AC Adapter
Dimensions
(H x W x D)
3 x 1.9 x 1.8 in (76 x 48 x 44 mm - including prongs), (may vary by model)
Cord Length
(approximate)
6 ft (1.83 m)
Power Supply Ratings
Voltage Range
100 to 240 V Switching
Input Current
0.4 A ac
Input Frequency
50 to 60 Hz
Output Voltage
5 V DC
Output Current
2 Amp
System Unit
Dimensions
(H x W x D)
4.47 x 2.78 x 0.5 in (113.6 x 70.6 x 13.5 mm)
Weight
4.4 oz (125 g)
Operating Temperature
32° to 104° F (0° to 40° C)
Storage Temperature
-4° to 140° F (-20° to 60° C)
Operating Humidity
90% RH
Regulatory Marks
Electrical
FCC Class B, UL or CSA NRTL, CE
Safety
C-UL, NOM
Design Features
4 programmable application quick-launch buttons, 5-way navigation joystick, touch-sensitive display for
stylus or fingertip, voice record button, microphone and speaker
QuickSpecs
HP iPAQ rx1950 Pocket PC
Standard Features
DA - 12255 North America — Version 5 — March 23, 2006
