ENWW 23
Table B-3 Model S2022a/S2022cp
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size 50.8 cm (20 in.) diagonal
Tilt -4 (+/-2)~+18 (+/-2)
Maximum Weight (unpacked) 3.4 kg(7.48 lbs)
Dimensions (h x w x d) 355.7 mm x 472.8 mm x 180 mm
14 x 18.6 x 7 in
Maximum Graphics Resolution 1600 x 900 @ 60 Hz
Optimum Graphics Resolution 1600 x 900 @ 60 Hz analog mode
Text Mode 720 x 400
Dot Pitch 0.2768 x 0.2768 mm/0.01 x 0.01 in
Horizontal Frequency (analog mode) 30 to 83 kHz
Vertical Frequency (analog mode) 55 to 75 Hz
Environmental Requirements
Temperature (independent of altitude)
Operating Temperature 41 to 95 F (5 to 35 C)
Non-Operating Temperature -4 to 140 F (-20 to 60 C)
Relative Humidity (non-condensing)
Operating Humidity 15% to 90%
Non-Operating Humidity 5% to 90%
Power Source 100-240V~, 50/60 Hz
Power Consumption 37 watts (W)
Sleep Power Consumption <1.0 watts (W)
