Middle frame
Description Spare part number
For use on HP Stream 8 Tablet 59xx models 796810-002
For use on HP Stream 8 Tablet 58xx models 796810-001
Before removing the middle frame, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 18).
Remove the middle frame:
1. Remove the ten Phillips PM1.3×4.5 screws (1) that secure the middle frame to the
display panel assembly.
2. Remove the middle frame (2).
Reverse this procedure to install the middle frame.
20 Chapter 5 Removal and replacement procedures
