2 Diagnostics and Troubleshooting
LEDs
Table 2-1 Power and IDE Flash Activity LEDs
LED Status
Power LED Off When the unit is plugged into the wall socket and the Power LED is off, the unit is powered off.
However, the network can trigger a Wake On LAN event in order to perform management
functions.
Power LED On Displays during boot sequence and while the unit is on. During boot sequence, hardware
initialization is processed and startup tests are performed on the following:
● Processor initialization
●
Memory detection and initialization
NOTE: If one of the tests fails, the unit will simply stop, but the LED will stay on. There
are no messages sent to video for any of these failed tests.
NOTE: The network LEDs are located inside the RJ-45 connector on the top, rear panel of the thin client. The LEDs are
visible when the connector is installed. Amber light indicates 100-MB/s speed connection and green light means 1-GB/s
speed connection. No light indicates 10-MB/s speed connection.
4 Chapter 2 Diagnostics and Troubleshooting
