Upgrading and Servicing Guide 11
3 Slide the memory module all the way into the memory slot, until the gold edge is almost completely
hidden in the slot, and then push down the outer edge of the memory module until the retaining clips
snap into place.
4 Close the HP TouchSmart PC. See “Closing the HP TouchSmart PC” on page 23.
CAUTION: The memory module must be inserted all the way into the slot before it is snapped
down into place; otherwise it will not work properly. In the following illustration, a memory
module is installed incorrectly (A), with the gold edge showing.
NOTE: If a blank screen is displayed after you replace or add a memory module, the memory is installed
incorrectly, or it is the wrong type of memory. Remove and reinstall the memory module.
A
