HP 2 m PremierFlex
HP 2 m PremierFlexHP 2 m PremierFlex
HP 2 m PremierFlex
OM3+ LC/LC Optical
OM3+ LC/LC OpticalOM3+ LC/LC Optical
OM3+ LC/LC Optical
Cable
CableCable
Cable
(BK839A)
Notes
NotesNotes
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)
thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a
longitudinal white stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m
added for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @
1310nm @ 23°C as tested in accordance with EIA 455-45
Services
ServicesServices
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 5 m PremierFlex
HP 5 m PremierFlexHP 5 m PremierFlex
HP 5 m PremierFlex
OM3+ LC/LC Optical
OM3+ LC/LC OpticalOM3+ LC/LC Optical
OM3+ LC/LC Optical
Cable
CableCable
Cable
(BK840A)
Notes
NotesNotes
Notes
Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.
• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um
• Bandwidth: 3000 MHz-km @ 850nm (Laser)
• Jacket Color: Blue
• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)
thermoplastic
• Boot Color: White
• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,
Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a
longitudinal white stripe that runs the entire length of the cable.
• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m
added for lengths >30m
• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @
1310nm @ 23°C as tested in accordance with EIA 455-45
Services
ServicesServices
Services
Refer to the HP website at
www.hp.com/networking/services
for details on the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 1810 Switch Series
HP 1810 Switch SeriesHP 1810 Switch Series
HP 1810 Switch Series
Accessory Product Details
DA - 13447 Worldwide — Version 9 — October 28, 2011
Page 20
