B Technical Specifications
HP Value Thermal Printer
Printer Specifications
Reliability
MCBF Printlines 72 million
MCBF Knife Cuts 3 million
Interface Powered USB (some models)
USB or Serial (some models)
Memory 2 MB flash memory, 512K RAM
Dimensions and Weight
Height 134 mm (5.34”)
Width 144 mm (5.66”)
Depth 184 mm (7.24”)
Weight 1.3 kg (2.9 lbs)
Power Requirements
Operating Voltage 24Vdc +/- 10%
+5 volts for logic circuit
Power Consumption 2.3 Amps maximum current draw
Temperature
Operating Temperature 5°C to 28°C (41°F to 82°F)
28°C to 45°C (82°F to 113°F)
Operating Humidity 10% to 90%
5% to 40%
Storage:
Temperature
Humidity
10°C to 50°C (14°F to 122°F)
5% to 90%
22 Appendix B Technical Specifications
