17" LCD Color Monitor HP VP17
47
Remove
main board
and power
board
1.Remove the
screws marked
in red to
remove the
main board,
power baord,
2.Disconnect
the connector
and remove
the power
board and
main board.
The end
The machine
disconnect
freely
