Page #68 background imageLoading...
Page #68 background image
You can use Windows tools to create system restore points and create backups of personal information,
see Using Windows tools on page 60.
If your computer does list the Recovery partition and the Windows partition, you can use HP Recovery
Manager to create recovery media after you successfully set up the computer. HP Recovery media can be
used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the
original operating system and software programs that were installed at the factory and then congures
the settings for the programs. HP Recovery media can also be used to customize the system or restore
the factory image if you replace the hard drive.
Only one set of recovery media can be created. Handle these recovery tools carefully, and keep
them in a safe place.
HP Recovery Manager examines the computer and determines the required storage capacity for
the media that will be required.
To create recovery discs, your computer must have an optical drive with DVD writer capability, and
you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use
rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray)
discs; they are not compatible with HP Recovery Manager software. Or, instead, you can use a high-
quality blank USB ash drive.
If your computer does not include an integrated optical drive with DVD writer capability, but you
would like to create DVD recovery media, you can use an external optical drive (purchased
separately) to create recovery discs. If you use an external optical drive, it must be connected
directly to a USB port on the computer; the drive cannot be connected to a USB port on an external
device, such as a USB hub. If you cannot create DVD media yourself, you can obtain recovery discs
for your computer from HP. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information on the HP website. Go to http://www.hp.com/
support, select your country or region, and follow the on-screen instructions.
Be sure that the computer is connected to AC power before you begin creating the recovery media.
The creation process can take an hour or more. Do not interrupt the creation process.
If necessary, you can exit the program before you have nished creating all of the recovery DVDs.
HP Recovery Manager will nish burning the current DVD. The next time you start HP Recovery
Manager, you will be prompted to continue.
To create HP Recovery media:
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning these steps.
1. Type recovery in the taskbar search box, and then select HP Recovery Manager.
2. Select Create recovery media, and then follow the on-screen instructions.
If you ever need to recover the system, see Recovering using HP Recovery Manager on page 61.
Using Windows tools
You can create recovery media, system restore points, and backups of personal information using Windows
tools.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
For more information and steps, see the Get started app.
Select the Start button, and then select the Get started app.
60 Chapter 9 Backing up, restoring, and recovering

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP X2 210 G2 and is the answer not in the manual?

HP X2 210 G2 Specifications

General IconGeneral
Form factorConvertible (Detachable)
Product typeHybrid (2-in-1)
Product colorSilver
Country of originChina
SteppingC0
Tjunction90 °C
Processor cache2 MB
Processor cores4
Processor familyIntel Atom®
Processor seriesIntel Atom x5 Series
Processor socketBGA 592
Processor codenameCherry Trail
Processor frequency1.44 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency1.84 GHz
Processor operating modes64-bit
PCI Express configurations1x1
Scenario Design Power (SDP)2 W
Maximum number of PCI Express lanes1
Numeric keypadNo
Pointing deviceTouchpad
Full-size keyboardYes
Internal memory2 GB
Internal memory typeDDR3L-SDRAM
Memory layout (slots x size)1 x 2 GB
Storage mediaeMMC
Total storage capacity32 GB
Compatible memory cardsMicroSD (TransFlash)
Display diagonal10.1 \
Touch technologyMulti-touch
Display resolution1280 x 800 pixels
Native aspect ratio16:10
Number of execution units12
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)500 MHz
Battery capacity32.5 Wh
Number of battery cells2
AC adapter power45 W
Audio decodersDTS Studio Sound
Rear camera resolution (numeric)5 MP
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Sustainability certificatesEPEAT Silver, ENERGY STAR
Processor codeSR29Z
Processor ARK ID87383
Processor package size17 x 17 mm
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth170 mm
Width265 mm
Height16.2 mm
Weight1090 g
Height (tablet mode)9.2 mm
Weight (tablet mode)580 g
