HP xw4400 Mini White Paper

Figure 1. Efficiency of Software RAID-0
Read Performance Write Performance Space Efficiency Reliability
Excellent Excellent ~100% Decreased
Read performance is
excellent, scaling
towards controller
maximum speed as
more disks are added.
The use of multiple
controllers will aid in
scaling.
Write performance is
excellent as well,
typically scaling even
better than reads.
Space efficiency is quite
good; there is very little
overhead.
RAID-0 offers no
protection against disk
crashes; in fact, it is
somewhat worse than
non-RAID configurations
because a single disk
crash is guaranteed to
affect the data spread
out over the array.
RAID-1: Mirroring
RAID-1, or mirroring, means that the data is copied or mirrored across multiple physical disks. The
data from a single physical disk or partition, once put into a RAID-1 array, will be copied
transparently to the other disks in the array. This provides increased reliability for data integrity;
should one disk fail, the data still remains on the other(s).
Tip:
Although RAID-1, as well as other RAID levels such as RAID-5, does provide
some data protection, this is only protection against common hardware
problems such as failure of a single disk. RAID should not be viewed as a
substitute for regular data back-ups.
Since it is possible to read from two (or more) disks at once, there is a possible performance increase
using RAID-1. Typically performance is sacrificed for recovery of data. Because data is mirrored, only
half of the physical space is utilized, and data must be replicated to multiple disks, marginally
increasing write times. Software RAID-1 is supported by HP Linux workstations.
Figure 2. Efficiency of Software RAID-1
Read Performance Write Performance Space Efficiency Reliability
Slight Improvement Somewhat Slower ~50% Excellent
Theoretically, RAID-1
configuration could
deliver higher read
performance, but there
have not been
significant gains seen
using software RAID-1.
Writes will be
fractionally slower than
non-RAID configurations
since data must be
replicated to several
disks.
Only 50% space
efficiency for two-disk
RAID-1, since the data
is fully replicated on
each disk.
Reliability is very good;
if one disk crashes, the
other(s) still have a full
copy of the data.
5

HP xw4400 Specifications

General

Processor	Intel Core 2 Duo
Chipset	Intel 975X
Memory	Up to 8 GB DDR2
Storage	SATA 3.0 Gb/s
Graphics	NVIDIA Quadro FX series
Operating System	Windows XP Professional
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 3 PCI
Ports	6 USB 2.0, 2 PS/2, 1 serial, 1 parallel, 1 RJ-45
Optical Drive	DVD-ROM
