Sliding Rack Mount Kit Installation
Page 4 of 10
Install the Rails to the Rack
To adjust slides (only necessary to fit shallower or deeper
non-HP racks)
1. Remove the slide adjustment attachment 1.
2. Adjust the rail to the desired length 2.
3. Insert the slide adjustment attachment 3.
1
2
3
A
A
