Integrated SATA RAID
RAID 0, RAID 1*, RAID 5 and RAID 10
Supports one RAID array with 2-4 drives
RAID 0 configuration - striped array (supported and configure to order under Microsoft
Windows Vista)
RAID 1 configuration - mirrored array
RAID 5 parity striping (supported but not configure to order under Microsoft Windows Vista)
RAID 10 stripe of mirrors (supported but not configure to order under Microsoft Windows
Vista)
NOTE:
HW RAID functionality not supported by Linux. Use SW RAID functionality provided in the
Red Hat Operating system instead.
SATA Connectors
4 ports/connectors
IEEE 1394a or 1394b
No integrated 1394a or 1394b – optional PCI card required.
Cable from Front IO can be plugged into PCI Card.
Not supported in Linux
USB 2.0 Connectors
8 (5 rear, 2 on header for front, 1 internal)
Power Supply Headers
Yes
Power Switch, Power
LED & Hard Drive LED
Header
Yes
Password Clear Header
Yes
Cooling Solutions
Power Supply Fan
92x25 mm variable speed
Processor Heatsink
Fan(s)
80x15 mm
Rear Chassis Fan(s)
Two 92x32 mm
Power Supply
Power Supply
575 Watt wide-ranging, active Power Factor Correction
Operating Voltage
Range
90 – 269 VAC
Rated Voltage Range
100 – 240 VAC
118 VAC
Rated Line Frequency
50/60Hz
400Hz
Operating Line
Frequency Range
47–66Hz
393–407Hz
Rated Input Current
10 A @ 100-120VAC
6 A @ 200-240 VAC
9.7 @ 118 VAC
Heat Dissipation
(configuration and
software dependent)
Typical 980 btu/hr (247 kg-cal/hr)
Maximum 3413 btu/hr (860 kg-cal/hr)
Power Supply Fan
92x25 mm variable speed
Blue Angel Compliant
(<5w in S5 – power off)
N/A
FEMP Standby Power
compliant @ 115V
(<2W in S5 – power off)
YES
QuickSpecs
HP xw6400 Workstation
Technical Specifications
DA - 12505 Worldwide — Version 21 — August 16, 2007
Page 25
