Form Factor
Form FactorForm Factor
Form Factor
Minitower
Color
ColorColor
Color
Carbonite/Alloy metallic
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots
(see
system board section for
more details)
2 PCI slots (full-length)
2 PCI Express x16 Gen2 graphics
2 PCI Express (x8 connectors, x4 electrically)
Bays
BaysBays
Bays
(see storage section
for more details)
Total Bays = 5 with 3.5" HDDs, or 6 with 2.5" HDDs
Front I/O
Front I/OFront I/O
Front I/O
2 USB 2.0, 1 headphone out, Microphone, optional IEEE 1394a
NOTE:
NOTE: NOTE:
NOTE:
Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux
Hardware Support Matrix (
http://www.hp.com/support/linux_hardware_matrix
) for details, and to the
Linux User Manual (
http://www.hp.com/support/linux_user_manual
) for tips on user-enablement of the
IEEE 1394 Card.
Internal I/O
Internal I/OInternal I/O
Internal I/O
1 USB 2.0 header, 1 serial port header for optional rear serial connector module.
Rear I/O
Rear I/ORear I/O
Rear I/O
5 USB 2.0, PS/2 keyboard and mouse, 1 RJ-45 to integrated Gigabit LAN, 1 audio line in, 1 audio line
out, 1 microphone in; audio ports can be retasked to function as line in, line out, microphone, or
headphone.
Chassis Dimensions
Chassis DimensionsChassis Dimensions
Chassis Dimensions
(H x W x D)
17.3 x 6.5 X 17.3 inches; 44.1 x 16.5 x 44.0 cm
System Weight
System WeightSystem Weight
System Weight
Exact weights depend upon configuration
Minimum: 31.7 lbs (14.4 kg)
Standard: 37.2 lbs (16.9 kg)
Maximum: 42.7 lbs (19.4 kg)
Temperature
TemperatureTemperature
Temperature
Operating
40° to 95° F (5° to 35° C)
Non-operating
-40° to 140° F (-40° to 60° C)
Humidity
HumidityHumidity
Humidity
Operating
8% to 85%
Non-operating
8% to 90%
Maximum Altitude
Maximum AltitudeMaximum Altitude
Maximum Altitude
(nonpressurized)
Operating
10,000 ft (3,000 m)
Non-operating
30,000 ft (9,100 m)
Power Supply
Power SupplyPower Supply
Power Supply
650W, 80 PLUS®, wide-ranging, active Power Factor Correction
Interfaces Supported
Interfaces SupportedInterfaces Supported
Interfaces Supported
-channel SATA interface (6 Serial-ATA connectors; 2 are eSATA configurable for use with eSATA After
Market Option kit), USB 2.0, IEEE 1394 (optional)
Hard Drive Controller
Hard Drive ControllerHard Drive Controller
Hard Drive Controller
Supported
SupportedSupported
Supported
SATA (integrated) or optional SAS (PCIe) controllers
QuickSpecs
HP xw6600 Workstation
HP xw6600 WorkstationHP xw6600 Workstation
HP xw6600 Workstation
Standard Features - Specs
DA - 12848 North America — Version 16 — November 25, 2008
Page 8
