HP xw8200

Write Methods Disc-at-once, session-at-once, track-at-once,
incremental fixed and variable packet, multi-
session
Access Times
(typical reads, including
settling)
CD-ROM Mode 1 < 125 ms
Full Stroke CD < 210 ms
Start-up Time (typical) < 7 s (single session), < 30 s (multi-session)
Stop Time (typical) < 4 s
Write Buffer Size 2 MB
Data Transfer Modes PIO Mode 4 (16.6 MB/s); Multi-word DMA
mode 2 (16.6 MB/s); UltraDMA Mode 2 (33.3
MB/s)
Power Source Four-pin, DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, < 1600 mA
maximum)
12 VDC (< 600 mA typical, < 1400 mA
maximum)
Total Drive Power
(standby mode)
< 2.5 Watt
Audio Output Line-Out 0.7 VRMS
Signal-to-Noise Ratio 74 dB
Channel Separation 65 dB
Configuration Jumper
Block
Master, slave, and cable select modes
Operating Conditions Temperature 41° to 122° F (5° to 50° C)
Humidity 10% to 90%10% to 90%
Certifications,
Approvals
MMC-3 support, multi-read compliant, Microsoft WHQL certification,
ACA AS/NZS 3548 class B, BSMI CNS 13438, CE Mark, C.I.S.P.R. Pub
22, TUV or VDE EN60950, EN 55022, EN55024, EMKO EN60950, EN
60825-1, UL 60950, CSA C22.2 60950-2000, CFR 21 part 1040 class 1,
CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, ANSI C63.4-1992
(FCC Class B)
Operating Systems
Supported
Microsoft Windows XP Professional, Microsoft Windows XP
Professional x64 Edition, Red Hat Enterprise Linux Workstation 3
Supplied Software (for
Windows XP)
Roxio Digital Media Plus: Create or copy CDs and DVDs, including
music and data CDs, and data DVDs
HP 48X CD-RW/DVD-
ROM Combo Drive
Form Factor 5.25-inch, half-height, tray-load
Mounting Orientation Horizontal or vertical
Interface ATAPI/EIDE
Dimensions (HxWxD) 5.77 x 1.71 x 7.87 [max] in (14.66 x 4.34 x 20.0 [max] cm) (external,
excluding bezel)
Weight (max) 2.6 lb (1.2 kg)
Read Only Disc
Parameters
Data Transfer Rates -
Read
CD read - 7200 KB/s (48X) Max
Digital audio extraction (minimum) - 1,800
KB/s (12X)
DVD ROM read - 21,632 KB/s (16X ) Max
Media and Formats -
Read
CD Media : stamped; CD-R; CD-RW (LS, HS,
US)
QuickSpecs
HP xw8200 Workstation
Technical Specifications - Optical Devices
DA - 11976 Worldwide QuickSpecs — Version 42 — 5.25.2007 Page 45
