HP xw8600

QuickSpecs
HP xw8600 Workstation
Technical Specifications
DA – 12849 Worldwide • Version 10 • June 1, 2008 Page 21
System Board
Chipset
Intel® 5400
Super I/O Controller
SMSC SCH5327
System Board Form
Factor
SSI-EEB (E-ATX 12" x 13")
Processor Socket
Dual LGA 771
DIMM Connectors
(FBD DDR2)
8 (16 with Risers)
PCI Connectors (5.0V)
1 half- length/full-height 33 MHz 32-Bit
PCI-X Connectors
1 full-length/full-height 133 MHz 64-Bit
PCI Express
Connectors
(all full-length/full-height)
1 PCI Express x16 Gen2 graphics slot 75W+75W
1 PCI Express x16 Gen2 (x16 or x8 selectable) 75W+75W
1 PCI Express x8 (x8 or x1 selectable)
2 PCI Express x8 (x4 electrically)
PCI Card Guide
Optional, tool-free support for all full-length cards with PCI extender
Flash ROM
Yes
Integrated Audio
High Definition Integrated Realtek ALC262 Audio with Line in, Line Out, Microphone, Headphone
CD-ROM IN (audio)
No
AUX IN (audio)
Yes
Clear CMOS Button
Yes
CPU Fan Headers
2
Chassis Fan Headers
2
Chassis Speaker
Header
Yes
CMOS Battery
Holder - Lithium
Yes
Hood Lock Header
Yes
Hood Sensor Header
Yes, as part of the front control panel header, connected by cable-to-switch. Cable/Switch
assembly is a configure-to-order option.
Multibay Header
No
Integrated Gigabit
Ethernet
2 Broadcom BCM5755 A2
Wake on LAN
Yes
Integrated Trusted
Platform Module
TPM 1.2
ASF 1.0 & 2.0 (Alert
Standard Format)
Yes
Integrated SATA
RAID*
§ RAID 0, 1, 10, 5
§ Supports one RAID array with 2-6 drives
§ RAID 0 configuration - striped array
§ RAID 0 configuration - data array
§ RAID 1 configuration - mirrored array
