QuickSpecs
HP xw8600 Workstation
Technical Specifications
DA – 12849 Worldwide • Version 10 • June 1, 2008 Page 23
Rated Voltage Range
100 – 240 VAC 118 VAC 100 – 240 VAC 118 VAC
Rated Line
Frequency
50/60Hz 400Hz 50/60 Hz 400Hz
Operating Line
Frequency Range
47 – 66 Hz 393 – 407 Hz 47 – 66 Hz 393 – 407 Hz
Rated Input Current
10.0A @ 100-127
VAC
6A @ 200-240 VAC
9.5A @ 118 VACC 13.2A @ 100-127
VAC
6.6A @ 200-240 VAC
12.0A @ 118 VAC
Heat Dissipation
(Configuration and
software dependent)
Typical 1530 btu/hr (386 kg-cal/hr)
Maximum 2027 btu/hr (511 kg-cal/hr)
Typical 3136 btu/hr (791 kg-cal/hr)
Maximum 4480 btu/hr (1129kg-cal/hr)
Power Supply Fan
92x32 mm variable speed 92x32 mm variable speed
Energy Star 4.0
Compliant
Yes Yes
80 PLUS® Compliant
Yes Yes
FEMP Standby
Power Compliant
@115V
(<2W in S5 –
with Wake on LAN
disabled)
Yes No
Power Consumption
in ES Mode –
Suspend to RAM (S3)
(Instantly Available PC)
<20W <25W
BIOS Features Description
PCI 3.0 Support
Full BIOS support for PCI Express through industry standard interfaces.
ASF 2.0 Compliant
Allows workstation status to be monitored on a remote console.
WMI Support
WMI is Microsoft's implementation of Web-
Based Enterprise Management (WBEM) for Windows.
WMI is fully compliant with the Distributed Management Task Force (DMTF) Common Information
Model (CIM) and WBEM specifications.
BIOS Boot Spec
1.01+
Provides more control over how and from what devices the workstation will boot.
Instantly Available
PC
Allows for very low power consumption with quick resume time
ROM Based F10
Setup and Power-on
Self Test
Review and customize BIOS settings
Remote System
Installation via F12
(PXE) (remote boot from
server)
Allows a new or existing system to boot over the network and download software, including the
operating system
System/Emergency
ROM Flash Recovery
Recovers corrupted system BIOS
