QuickSpecs
HP xw8600 Workstation
Standard Features - Custom Components
DA – 12849 Worldwide • Version 10 • June 1, 2008 Page 4
SAS) Linux
80 GB 7200 rpm SATA 3.0 Gb/s drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
160 GB 7200 rpm SATA 3.0 Gb/s NCQ*
drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
250 GB 7200 rpm SATA 3.0 Gb/s NCQ*
drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
500 GB 7200 rpm SATA 3.0 Gb/s NCQ*
drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
1 TB 7200 rpm SATA 3.0 Gb/s NCQ*
drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
80 GB 10K rpm SATA NCQ* drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
160 GB 10K rpm SATA NCQ* drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
160 GB 10K rpm SATA NCQ** drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
SAS Hard Drive
(8 port SAS Controller included on the
system board)
Windows
Vista
i
Windows XP Red Hat
Enterprise
Linux
146 GB 10K rpm Small Form Factor SAS
3.0 Gb/s drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
73 GB 10K rpm Small Form Factor SAS 3.0
Gb/s drive
32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
73 GB 15K rpm SAS 3.0 Gb/s drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
146 GB 15K rpm SAS 3.0 Gb/s drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
300 GB 15K rpm SAS 3.0 Gb/s drive 32-Bit, 64-Bit 32-Bit, 64-Bit WS 4 & 5
drives, 5 SAS* drives,
or 6 SAS Small Form
Factor (SFF)* drives
* NCQ (Native Command Queuing) not supported in Red Hat Enterprise Linux
Windows
Vista
i
Windows XP Red Hat
Enterprise
Linux
RAID 0 Configuration - Striped Array
Minimum of 2 hard drives needed. All hard
drives must be identical
(size/speed/type/bus/functional
capabilities).
Must have 2, 3 or 4 HD Drives.
32-Bit, 64-Bit 32-Bit, 64-Bit Not supported
RAID 0 Configuration - Data Array
Minimum of 3 SATA hard drives needed. All
hard drives must be identical
(size/speed/type/bus/functional
capabilities).
At least 3 HD Drives required. May have 4th
and 5th HD Drives. Drives must be the same
drive (size/speed/type/functional
capability).
Not factory
integrated
32-Bit, 64-Bit Not supported
Factory Integrated
RAID* on
motherboard for
SATA and SAS
drives
All RAID arrays must be
less than 2 TB in size
RAID 1 Configuration
-
Mirrored Array
32-Bit, 64-Bit 32-Bit, 64-Bit Not supported

HP xw8600 Specifications

General

Chipset	Intel 5400
Form Factor	Tower
Processor	Intel Xeon 5400 series
Memory	Up to 32GB DDR2 FB-DIMM
Storage	SATA or SAS hard drives
Graphics	NVIDIA Quadro or ATI FirePro
Operating System	Windows XP, Vista, or Linux
Expansion Slots	PCI, PCI-X, PCIe
Power Supply	800W
