HP Z220 User Manual

Controller Cards
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
HP IEEE 1394b FireWire PCIe Card Y Y NK653AA See Note
1
HP USB 3.0 2x2 Port SuperSpeed PCIe x1 Card N Y QT587AA See Note
2
NOTE 1: For the HP Z220 CMT Workstation the 1394b card is only supported on Slots 3, 4, or 5.
NOTE 2: Four USB 3.0 ports are available integrated on the motherboard (2 front, 2 rear). Integrated USB
3.0 ports are supported under Windows 7 operating system only. The USB 3.0 2x2 Port SuperSpeed PCIe
card is required if Windows XP operating systems support is required (supported as AMO only).
Networking and
Communications Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
Integrated Intel 82579LM PCIe GbE Controller Y N
Intel Gigabit CT Desktop NIC Y Y FH969AA
Broadcom NetXtreme Gigabit Ethernet Plus NIC (PCIe) N Y FS215AA
HP X520 10GbE Dual Port Adapter Y Y C3N52AA
HP 10GbE SFP+ SR Transceiver Y Y C3N53AA
NOTE 1: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.
The Intel Gigabit CT NIC is supported on the following operating systems:
Microsoft Windows XP Pro 32-bit and 64-bit and Microsoft Windows 7 32-bit and 64-bit versions.
Red Hat Enterprise Linux (RHEL),
Novell SLED 11
NOTE 2: The integrated network connection is required to support Intel vPro Technology.
NOTE 3: If AMT is enabled network teaming with the built in LAN port is not possible.
NOTE 4: DASH remote manageability support is not available with the Broadcom NIC when used on the
Z220 workstation.
Racking and Physical
Security Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP xw4/Z2/Z4 Depth Adjustable Fixed Rail Rack Kit N Y WH340AA
Security Cable with Kensington Lock N Y PC766A
HP Solenoid Hood Lock & Hood Sensor Y Y DE618A
HP Business PC Security Lock Kit N Y PV606AA
QuickSpecs
HP Z220 CMT Workstation
Supported Components
DA - 14286 North America — Version 20 — November 21, 2013 Page 12

HP Z220 Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1225V2
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Thermal Design Power (TDP)	77 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	32
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel PCH C216
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Graphics card	HD Graphics P4000
Rack mounting	-
Networking features	Gigabit Ethernet (10/100/1000)
PS/2 ports quantity	2
Serial ports quantity	0
USB 2.0 ports quantity	9
Chassis type	Minitower
Country of origin	China
Number of 3.5\" bays	3
Operating system installed	Windows 7 Professional
Power supply	400 W
On-board graphics card model	Intel® HD Graphics P4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Processor ARK ID	65733
Intel TSX-NI version	0.00
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	445 mm
Width	178 mm
Height	447 mm
Weight	10400 g
