Page #15 background imageLoading...
Page #15 background image
System Board
System Board Form Factor
ATX 244 x 305 mm (9.6 x 12 inches)
Processor Socket
Single LGA-1155
CPU Bus Speed
DMI
Chipset
Intel® PCH C216
Memory Expansion Slots
4 DDR3 memory slots
Memory Type Supported
DDR3, UDIMM (Unbuffered), ECC& non-ECC
Memory Modes
Non-Interleaved for single channel. Interleaved when both channels are populated.
Memory Speed Supported
1600MHz DDR3
Memory Protection
ECC available on data
Maximum Memory
32GB
Memory Configuration
(Supported)
2GB,4GB and 8GB ECC or non-ECC unbuffered DIMMs are supported.
ECC and non-ECC memory DIMMs cannot be mixed on the same system.
NOTE:
Maximum memory capacities assume 64-bit operating systems, such as genuine Genuine
Windows® 7 Professional 64-Bit or Red Hat Linux 64-bit. 32-bit Windows Operating Systems support up to
4 GB.
PCI Express Connectors
- 1 PCI Express Gen2 slot x8 mechanical/ x4 electrical (full height, half length)
- 1 PCI Express Gen3 slot x16 mechanical/ x16 electrical (full height, full length)
- 1 PCI Express Gen2 slot x1 mechanical/ x1 electrical (full height)
- 1 PCI Express Gen2 slot x16 mechanical/ x4 electrical (full height, full length)
- 1 PCI Express Gen2 slot x1 mechanical/ x1 electrical (full height)
NOTE:
The PCIe x8 connector is open ended, allowing a PCIe x16 card to be seated in the slot. However,
this slot supports only half length cards.
In the PCIe Gen3 (x16 electrical/x16 mechanical) slot, if it is not being used for a graphics card, only cards
certified as After Market Options for this platform are supported.
PCI Connectors
(5.0V)
2 PCI slots, full height, full length
Supported Drive
Interfaces
SATA
Integrated (6) Serial ATA interfaces (2x 6Gb/s SATA, 4x 3Gb/s
SATA). One port can optionally be used for eSATA). RAID 0 and 1
supported. (Factory integrated RAID is Microsoft Windows
only). RAID 5 is supported by Software XOR.
Serial Attached SCSI
None
Integrated RAID
NOTE:
Requires identical hard drives (speeds, capacity,
interface)
Integrated Graphics
Integrated Intel HD Graphics(on Pentium G640 processor);
Integrated Intel HD Graphics 4000 (on Core i7-3xxx processors);
Integrated Intel HD Graphics P4000 (on Intel Xeon E3-12x5v2
processors).
Unified Memory Architecture (UMA)- A region of system
memory is reserved and dedicated to the graphics display.
Support for Microsoft DirectX 10.1; OpenGL 3.0 on Intel HD
Graphics P4000;
1 DVI-I and 1 DP 1.1 graphics ports integrated in motherboard;
Supports dual displays across DP & DVI-I outputs.
QuickSpecs
HP Z220 CMT Workstation
System Technical Specifications
DA - 14286 North America — Version 20 — November 21, 2013
Page 15
