Intel® Pentium®
G2020 processor
2
2.9
N/A
3 1333
N
Intel HD
Graphics
N
55W
1
The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs in
100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
Available Processor
Disclaimers
Integrated Intel® HD graphics is not supported on the Intel Xeon processor E3-1230v2, E3-1240v2, E3-
1270v2, E3-1280v2 or E3-1290v2.
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:
http://www.intel.com/products/processor_number/
for details.
64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:
http://www.intel.com/info/em64t
for more
information.
Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.
Color
Jack Black
Convertibility
Yes. 5.25" drives rotate for Minitower or Desktop orientation.
Expansion Slots
(see
system board section for
more details)
1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x4 slot /x8 connector
2 PCIe Gen 2 x1 slot
2 PCI slots
NOTE:
The PCIe x8 connector is open ended, allowing a PCIe x16 card to be seated in the slot. However,
this slot supports only half length cards.
In the PCIe Gen3 x16 slot, if it is not being used for a graphics card, only cards certified as After Market
Options for this platform are supported.
Expansion Bays
(see
storage section for more
details)
3 internal 3.5" bays
3 external 5.25" bays
NOTE:
Third external 5.25" bay is not full depth; maximum depth 170 mm (6.7 inches)
Front I/O
2 USB 3.0, 1 USB 2.0, 1 IEEE 1394a (requires optional PCIe card to function), 1 Headphone, and 1
Microphone.
Internal I/O
5 USB 2.0 ports available by two separate 2x5 and one 1x5 header:
supports one HP Internal USB Port Kit (one port on each Kit) for 1x5 pin header plus
(a) up to two USB Media Card Readers, or (b) one Internal Port kit and one USB Media Card Reader.
Rear I/O
1 DVI-I Single Link and 1 DisplayPort (DP 1.1) output from Intel HD graphics (available on selected
processors only), 2 USB 3.0, 4 USB 2.0, 1 optional serial port, 2 PS/2, RJ-45 (NIC), 1 Audio Line-in, 1 Audio
Line-out, 1 Microphone; 2 IEEE 1394b ports (optional)
Interfaces Supported
22-in-1 Media Card Reader (optional)
Chassis Dimensions
(H x W x D)
Standard minitower orientation: 447 x 178 x 455 mm (17.6 x 7 x 17.9 in); Converted desktop orientation:
178 x 447 x 455 mm (7 x 17.6 x 17.9 in)
Weight
Exact weights depend upon configuration:
Minimum: 10.4 :kg (22.9 lbs)
Typical
*
: 11.6 kg (25.5 lbs) Maximum: 14.8 kg (32.6 lbs)
Max Supported Weight (desktop orientation) 35 kg (77 lb)
QuickSpecs
HP Z220 CMT Workstation
Overview
DA - 14286 North America — Version 20 — November 21, 2013
Page 4
