1.
2.
Notes Quadro K2000 offered as CTO does not include a video cable adapter.
Video cable adapters must be ordered separately.
Quadro K2000 offered as AMO includes one DP-to-DVI video cable
adapter. Additional cables must be ordered separately.
NVIDIA Quadro K4000 3GB
Graphics
Form Factor 4.376" H x 9.5" L
Single Slot, Full Height
Graphics Controller NVIDIA Quadro K4000 Graphics Card
Kepler GK106 GPU
768 CUDA cores
Max Power: 80 Watts
Bus Type PCI Express 2.0 x16
Memory 3 GB GDDR5, 2800 Mhz
192-bit memory I/O path
134 GB/s memory bandwidth
Connectors 1 DL-DVI(I) output, 2 DisplayPort outputs
CTO: No video cable adapter included
AMO: One DP-to-DVI adapter included with card
Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters
are available as accessories
Maximum Resolution DisplayPort:
- up to 3840 x 2160 x 30 bpp @ 60Hz
- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)
DL-DVI(I) output:
- up to 2560 x 1600 x 32 bpp @ 60Hz
Image Quality Features 10-bit internal display processing pipeline
10-bit scan-out support
Display Output VGA:
- requires use of DVI-to-VGA and/or DP-to-VGA video cable adapters
- 400 Mhz integrated RAMDAC
- Max resolution: 2048 x 1536 x 32 bpp @ 85 Hz
DL-DVI(I):
- Max resolution: 2560 x 1600 x 32 bpp @ 60 Hz
SL-DVI(I):
- Max resolution: 1920 x 1200 x 32 bpp @ 60 Hz
DisplayPort:
- Supports HBR2 and MST
- Max resolution: 3840 x 2160 x 30 bpp @ 60 Hz (only one monitor can be
connected to a Quadro K4000 DisplayPort connector at this resolution)
- Max number of DisplayPort daisy-chained monitors or hub connected
monitors from a single Quadro K4000 DisplayPort connector: 4 with maximum
resolution of 1920 x 1200
HDMI:
QuickSpecs
HP Z220 CMT Workstation
Technical Specifications - Graphics
DA - 14286 North America — Version 20 — November 21, 2013 Page 43
