GASCABINETHEATER USER MANUAL
6
• DO NOT use abrasive products to clean the heater.
• The pilot light whilst in operation should burn steadily, if it ickers or is yellow tipped, the heater should
be checked for correct operation.
• If any parts need replacement, they must be replaced only with genuine original parts supplied by the
manufacturer. The use of incorrect or substitute parts may be dangerous and will void any warranty.
• Do not use a wet cloth or allow the appliance to become wet when cleaning, this may prevent the heater
working correctly.
• When the heater is not in use leave in a clean and dry area.
TECHNICAL DATA:
Gas Heat Output 4.1 kW
Gas category, gas pressure, gas type and destination countries:
*13+ (28-30/37): Butane/propane and their mixtures;
Butane at 28-30mbar; Propane at 37mbar.
BE,FR,IT,LU,LV,IE,GB,GR,PT,ES,CY,CZ,LT,SK,CH,SI.
Pin Code (CE): 2531 CT-0032
Pin Code (UKCA): 8504DN-0001
Products Size: 730x420x352 mm
Weight: N.W: 8.0kg, G.W 9.5kg
Serial No.:
• Gas Heat Input: Minimum 1.5kW Medium 2.8kW Maximum 4.1kW
• Gas Consumption: Minimum 109g/h Medium 204g/h Maximum 298g/h
• Ignition System: Piezo electric / Pulser Ignition / Button Type
• Cylinder Type: Upto 15kg
• Gas Hose: Certied according to applicable EN-standard (Recommended 50cm)
• Gas Regulator: Certied according to EN16129 (ow rate max 1.5kg/h)
• This product is not suitable for primary heating purposes
• The energy efciency class: Class A
• The direct heat output: 4.1 kW
• The energy efciency index: EEl=89%.
• Please refer to the instruction manual for the assembly, installation, maintenance, disassembly, recycling
and/ or disposal at end-of-life.
• This gas heater is in conformity with following EC directive and Regulations:
Gas Appliances Regulation(EU) 2016/426(GAR)
Commission Delegated Regulation (EU) 2015//1186 and 2015/1188
And that the following harmonised standards have been applied:
EN449:2002 + A 1 :2007
2531 8504-23
