HSP NTG-3000 - Introduction; Transport and Storage; Storage temperature; Mechanical strength

HSP GmbH Zum Handwerkerhof 2 90530 Wendelstein Tel. 09129 / 2852-0 Fax: 09129 / 2852-11 Web: www.hsshsp.de EMAIL: HSP@hsshsp.de
NTG-3000 Operating Instructions Version 2.11
Page 4 of 18
1 Introduction
This transformer is used in power plants. It forms part of a control circuit that acquires actual
values for the currents and voltages of a generator and forwards them to the control unit via
Ethernet/PROFIBUS.
This document describes installation, connection and startup of the transducer.
2 Scope of application of this document
These Operating Instructions only apply to transducer NTG-3000.
Software Version >=3.8
Hardware Rev. 5.1
3 Transport and storage
3.1 Storage temperature
-20°C to +70°C, maximum rate of change: 20 K/h
IEC 60068-2-1 and IEC 60068-2-2
3.2 Mechanical strength
When stationary: DIN IEC 60068-2-6
Deflection: 0.075 mm (5 - 9 Hz)
Acceleration: 1 m/s
2
(>9 -200 Hz)
During transport: DIN IEC 60068-2-6
Deflection: 3.5 mm (5 - 9 Hz)
Acceleration: 10 m/s
2
(>9 -500 Hz)
4 Environment category
Environment 2 as per EN 61800-3.
5 Installation instructions
The device is designed for installation on a standard DIN mounting rail (DIN EN 60715 TH
35). Other methods of mounting are not permitted.
Permissible mounting position: Horizontal
