HST EPS Series - Installation Dimensions & Technical Data

5
Model
Size (mm)
L1
L2
B1
B2
H1
H2
G
Connection
HSTEPS 25-4 180
90
180
45
90
90
127
1½”
1”
HSTEPS 25-6 180
90
180
45
90
90
127
1½”
1”
HSTEPS 25-7.5 180
90
180
45
90
90
127
1½”
1”
HSTEPS 32-4 180
90
180
45
90
90
127
2”
1¼”
HSTEPS 32-6 180
90
180
45
90
90
127
2”
1¼”
HSTEPS 32-7.5 180
90
180
52
99
128
156
2”
1¼”
HSTEPS 20-6 130
65
130
45
90
94
122
1”
¾”
HSTEPS 25-4 130
65
130
45
90
90
127
1½”
1”
HSTEPS 25-6 130
65
130
45
90
90
127
1½”
1”
HSTEPS 25-11 180
90
180
66
132
132
170
1½”
1”
HSTEPS 32-11 180
90
180
66
132
132
170
2”
1¼”
max.head
max. Flow
power consumption
voltage
mains frequency
HSTEPS 25-4 180
4m
2,5 m
3
/h
5 – 22 Watt
230V
50 Hz /60 Hz
HSTEPS 25-6 180
6m
3,2 m
3
/h
5 – 45 Watt
HSTEPS 25-7.5 180
7,5m
3,4 m
3
/h
5 – 70 Watt
HSTEPS 32-4 180
4m
2,8 m
3
/h
5 – 22 Watt
HSTEPS 32-6 180
6m
3,6 m
3
/h
5 – 45 Watt
HSTEPS 32-7.5 180
7,5m
3,8 m
3
/h
5 – 70 Watt
HSTEPS 20-6 130
6m
2,8 m
3
/h
5 – 45 Watt
HSTEPS 25-4 130
4m
2,5 m
3
/h
5 – 22 Watt
HSTEPS 25-6 130
6m
3,2 m
3
/h
5 – 45 Watt
HSTEPS 25-11 180
11m
5,5 m
3
/h
5 - 140 Watt
HSTEPS 32-11 180
11m
7,0 m
3
/h
5 - 140 Watt
INSTALLATION DIMENSIONS & TECHNICAL DATA
