HT7
EN - 14
6.1.3. General specifications
Mechanical characteristics
Dimensions (L x W x H): 240 x 78 x 40mm (9.4 x 3.1 x 1.6in)
Weight (including batteries): 240g (7.7ounces)
Power supply
Battery type: 2x1.5V batteries type AAA LR03
Indication of low batteries: " "is displayed
Auto power off / on fixed
Display
Type: 3½ digits LCD, max. 1999 counts + sign,
bargraph and backlight
6.2. ENVIRONMENT
6.2.1. Environmental conditions
Reference temperature of calibration: 23 ± 5°C (73 ± 41°F)
Operating temperature: -10 ÷ 55°C (14 ÷ 131°F)
Allowable relative humidity: <85%RH
Storage temperature: -10 ÷ 60°C (14 ÷ 140°F)
Storage humidity: <85%RH
This instrument complies with the
European Directive on low voltage
(LVD) and with EMC 2004/108/CE
6.3. ACCESSORIES
6.3.1. Standard accessories
Plastic protection of metal probes
4mm metal sleeves with internal thread, 2x
Batteries, 2x 1,5V AAA
User manual
6.3.2. Optional accessories
Carrying bag B71
