Huawei 3 U - Page 10

Installing a Device
5
4
Install the 19-inch mounting ears and conversion mounting ears
on the left and right sides of the device.
5
Connect the PGND cable to the front or side face of the device.
The side face is preferred.
6
Install the device into the cabinet.
x4
x4
M4
M6
x4
x4
M6
