Installing a Device
5
5.2 Installing a Device in an ETSI 21-Inch Cabinet
with Front Columns
2
Install the cable management frame
and power cable tray onto the device.
1
Install floating nuts onto the cabinet.
4
Install the device into the cabinet.
x4
x4
M6
Installation hole
Floating nut
x2
x2
M3
