Huawei AR120 User Manual

Item Specification
Operating
environment
temperature
-40°C to +65°C (-40°F to +149°F)
NOTE
In compliance with IEC60068-2-1-2007 and ETSI EN 300 019-2-3
V2.2.2:2003, the router can operate reliably for 24 hours in a temperature
range of -40°C to +70°C (-40°F to +158F).
Storage
temperature
-40°C to +85°C (-40°F to +185°F)
Operating relative
humidity
5% to 95%, noncondensing
Operating altitude < 5000 m (16404 ft.)
Part number 02350KKH
7.5.2 AR2504E-H
Technical Specifications
Table 7-26 lists technical specifications of the AR2504E-H router.
Table 7-26 AR2504E-H technical specifications
Item
Specification
System parameters
Processor Dual-core, 533 MHz
Memory 2 GB
Flash memory 512 MB
Dimensions (W x
D x H)
l With no mounting bracket installed: 442.0 mm x 420.0 mm x 44.4
mm (17.4 in. x 17.4 in. x 1.7 in.)
l With mounting brackets installed: 482.0 mm x 420.0 mm x 44.4
mm (19.0 in. x 17.4 in. x 1.7 in.)
Weight (empty
chassis)
7 kg (15.4 lb)
Power consumption (empty chassis)
Typical power
consumption
20 W
Maximum power
consumption
28 W
Power specifications
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description
7 Technical Specifications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
124

Huawei AR120 Specifications

General

SIC Slots	2
VSU	No
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Memory	512 MB
Flash Memory	256 MB
Operating Humidity	5% to 95% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Type	Network Router
Power Supply	AC 100-240V, 50/60Hz
Dimensions (H x W x D)	220 mm
