Figure 6-26 Appearance of the 4G.SHDSL cable
Figure 6-27 shows the structure of the 4G.SHDSL cable.
Figure 6-27 Structure of the 4G.SHDSL cable
X1
1 8
Main Label
X2
X3
X4
X5
1
6
Network port connector
(8-pin, RJ-45)
Label 1
Label 2
Label 3
Label 4
6-pin connector
Pin Assignments
Table 6-18 describes the pin assignments of the 4G.SHDSL cable.
