5
Optional: Installing the external antenna
In areas with poor reception, connect external antenna to the B315's external antenna
port to improve signal reception.
1. Power off the B315 and disconnect it from the power outlet.
2. Use a small tool, such as a paper clip, to remove the cover from the antenna ports.
Store the cover in a safe place.
3. Install one or two external antennae depending upon the signal strength. Make sure
the external antennae are securely connected to the antennae ports.
For weak indoor signal strength, an omni-directional outdoor antenna can be purchased
from Telkom SA SOC Ltd. It is recommended that only 1 antenna be used.
If you are using only one external antenna, connect it to port 1.
The external antenna
e may/may not be supplied with the device.
Before installing the external antenna, ensure that the B315 is powered off and
disconnected from the power outlet.
The external antenna that is supplied with the device can only be used indoors.

Other manuals for Huawei B315

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei B315 and is the answer not in the manual?

Huawei B315 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Wi-Fi band-
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)150 Mbit/s
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
4G standardLTE
2G standardsGSM
3G standardsUMTS
Product typeTabletop router
Product colorWhite
Power source typeAC
Weight and Dimensions IconWeight and Dimensions
Depth46 mm
Width139 mm
Height186 mm
Weight275 g
